Which one of those?

#1

Post by lindsay » 25 Jan 2017 07:39

I am looking at Asrock C2750D4I and Asrock C2550D4I

This one is only gonna serve movies,music,tv-shows beside backups of clients.

And it has 12 Sata wich is enough for the rack i am gonna get and use the PCIe to 10Gbps networkcard

Asrock C2550D4I seems to be the best choice and cheapest

It is gonna be with mirror zfs 10X8TB and 2x4TB hdd`s
Protected by smoothiebox Red,Green,
Purple,Orange Zones/VLAN`s
Powered by AMD A10-6700T


XigmaNAS Box-1 11.2.0.4 - Omnius (revision 6625)
Platform : x64-embedded on 2X Intel(R) Xeon(R) CPU E5-2620 v4 @ 2.10GHz
Motherboard: ASUS Z10PA-D8, 2xSocket-2011-3
SATA Controllers : 1X Avago Technologies (LSI) SAS2008 and 1x Avago Technologies (LSI) SAS2308
Pool 1 (Media-Pool) 8X4TB in raidz2
Pool 2 (Media-Pool-2) 4X2TB in raidz2 and 2X2TB in mirror mirror and 2X3TB in mirror
Pool 3 (Media-Pool-3) 2X2TB in mirror and 2X4TB in mirror and 2X1TB in mirror

User avatar
crowi
Forum Moderator
Forum Moderator
Posts: 1184
Joined: 21 Feb 2013 16:18
Location: Munich, Germany
Status: Offline

Re: Which one of those?

#2

Post by crowi » 25 Jan 2017 07:54

I am using C2550D4I since some years now, be careful with the memory, some kingston ECC did not work. Stick to the recommendations on the QVL
http://www.asrockrack.com/general/produ ... D4I#Memory

Besides this, the board is nice and running fine.
NAS 1: Milchkuh: Asrock C2550D4I, Intel Avoton C2550 Quad-Core, 16GB DDR3 ECC, 5x3TB WD Red RaidZ1 +60 GB SSD for ZIL/L2ARC, APC-Back UPS 350 CS, NAS4Free 11.0.0.4.3460 embedded
NAS 2: Backup: HP N54L, 8 GB ECC RAM, 4x4 TB WD Red, RaidZ1, NAS4Free 11.0.0.4.3460 embedded
NAS 3: Office: HP N54L, 8 GB ECC RAM, 2x3 TB WD Red, ZFS Mirror, APC-Back UPS 350 CS NAS4Free 11.0.0.4.3460 embedded

User avatar
ChriZathens
Forum Moderator
Forum Moderator
Posts: 833
Joined: 23 Jun 2012 09:14
Location: Athens, Greece
Contact:
Status: Offline

Re: Which one of those?

#3

Post by ChriZathens » 25 Jan 2017 18:24

If you have a case that can hold 12 drives, then it should have enough room for a uATX motherboard.
Go for a supermicro uATX, probably the x10SL7-F (14 sata ports)
With a respectable CPU it should cost the same, you will have more options for additional cards, more options to upgrade in the future and more reliability (there have been a lot of reports about BMC problems with those particular mobos)
My Nas
  1. Case: Fractal Design Define R2
  2. M/B: Supermicro x9scl-f
  3. CPU: Intel Celeron G1620
  4. RAM: 16GB DDR3 ECC (2 x Kingston KVR1333D3E9S/8G)
  5. PSU: Chieftec 850w 80+ modular
  6. Storage: 8x2TB HDDs in a RaidZ2 array ~ 10.1 TB usable disk space
  7. O/S: XigmaNAS 11.2.0.4.6625 -amd64 embedded
  8. Extra H/W: Dell Perc H310 SAS controller, crosflashed to LSI 9211-8i IT mode, 8GB Innodisk D150SV SATADOM for O/S

Backup Nas: HP N40L (4x1TB HP branded Seagate disks in RaidZ configuration - 8GB ECC RAM)

User avatar
zoon01
Developer
Developer
Posts: 768
Joined: 20 Jun 2012 21:06
Location: Netherlands
Contact:
Status: Offline

Re: Which one of those?

#4

Post by zoon01 » 28 Jan 2017 08:15

From me here another vote to go for the Supermicro https://www.supermicro.nl/products/moth ... 0SL7-F.cfm X10SL7-F.
System specs: XigmaNAS 11.2.0.4 -embedded on Samsung 860 EVO 256GB and Supermicro X10SL7-F w / Bios v3.2, IPMI v.03.84 / CPU E3-1241 v3 @ 3.50GHz - 32GB Crucial DDR3L 1600mhz ECC 1.35v , LSI 2308 on PH20.00.07.00 IT mode, Storage: 5x Western Digital Red (WD30EFRX) raidz

Development system is same system in virtualbox.

User avatar
apollo567
Site Admin
Site Admin
Posts: 716
Joined: 23 Jun 2012 06:37
Location: Ludwigshafen, Germany
Status: Offline

Re: Which one of those?

#5

Post by apollo567 » 28 Jan 2017 10:47

Agreed, since I have my supermicro Board things got much more uncomplicated......
look at ebay for a cheap offer
my NAS and its development until today: viewtopic.php?f=63&t=39&sid=039fed830cf ... 4d0abe4a04

User avatar
lindsay
Forum Moderator
Forum Moderator
Posts: 307
Joined: 23 Jun 2012 09:59
Location: Steinkjer,Norway
Status: Offline

Re: Which one of those?

#6

Post by lindsay » 28 Jan 2017 17:45

zoon01 wrote:
28 Jan 2017 08:15
From me here another vote to go for the Supermicro https://www.supermicro.nl/products/moth ... 0SL7-F.cfm X10SL7-F.
I like this one as it can be used with an 4X1Gbps cards beside the 2 internals and a 10Gbps card and it has 12xSATA

With IPMI you can use rack console? (8-port kvm switch)


And does WOL works with this board?
Protected by smoothiebox Red,Green,
Purple,Orange Zones/VLAN`s
Powered by AMD A10-6700T


XigmaNAS Box-1 11.2.0.4 - Omnius (revision 6625)
Platform : x64-embedded on 2X Intel(R) Xeon(R) CPU E5-2620 v4 @ 2.10GHz
Motherboard: ASUS Z10PA-D8, 2xSocket-2011-3
SATA Controllers : 1X Avago Technologies (LSI) SAS2008 and 1x Avago Technologies (LSI) SAS2308
Pool 1 (Media-Pool) 8X4TB in raidz2
Pool 2 (Media-Pool-2) 4X2TB in raidz2 and 2X2TB in mirror mirror and 2X3TB in mirror
Pool 3 (Media-Pool-3) 2X2TB in mirror and 2X4TB in mirror and 2X1TB in mirror

User avatar
zoon01
Developer
Developer
Posts: 768
Joined: 20 Jun 2012 21:06
Location: Netherlands
Contact:
Status: Offline

Re: Which one of those?

#7

Post by zoon01 » 28 Jan 2017 19:20

Our servers do run headless, no need for a keyboard and screen :P

Other than that, its an Belkin, i have nothing personal with their products.
System specs: XigmaNAS 11.2.0.4 -embedded on Samsung 860 EVO 256GB and Supermicro X10SL7-F w / Bios v3.2, IPMI v.03.84 / CPU E3-1241 v3 @ 3.50GHz - 32GB Crucial DDR3L 1600mhz ECC 1.35v , LSI 2308 on PH20.00.07.00 IT mode, Storage: 5x Western Digital Red (WD30EFRX) raidz

Development system is same system in virtualbox.

User avatar
lindsay
Forum Moderator
Forum Moderator
Posts: 307
Joined: 23 Jun 2012 09:59
Location: Steinkjer,Norway
Status: Offline

Re: Which one of those?

#8

Post by lindsay » 28 Jan 2017 19:25

It is not only for nas4free but for others too as sometimes i have to reinstall.
I know it is not needed but nice to have
Protected by smoothiebox Red,Green,
Purple,Orange Zones/VLAN`s
Powered by AMD A10-6700T


XigmaNAS Box-1 11.2.0.4 - Omnius (revision 6625)
Platform : x64-embedded on 2X Intel(R) Xeon(R) CPU E5-2620 v4 @ 2.10GHz
Motherboard: ASUS Z10PA-D8, 2xSocket-2011-3
SATA Controllers : 1X Avago Technologies (LSI) SAS2008 and 1x Avago Technologies (LSI) SAS2308
Pool 1 (Media-Pool) 8X4TB in raidz2
Pool 2 (Media-Pool-2) 4X2TB in raidz2 and 2X2TB in mirror mirror and 2X3TB in mirror
Pool 3 (Media-Pool-3) 2X2TB in mirror and 2X4TB in mirror and 2X1TB in mirror

User avatar
lindsay
Forum Moderator
Forum Moderator
Posts: 307
Joined: 23 Jun 2012 09:59
Location: Steinkjer,Norway
Status: Offline

Re: Which one of those?

#9

Post by lindsay » 12 Apr 2017 22:37

It is going to be this mainboard ASUS Z10PA-D8, 2xSocket-2011-3 and expand later when needed.
It is expensive With 2x xenon and memory if you go to fill all memory banks.
I am going to ask the webshop wich memory will work With this Board.

Not to mention all the hdd`s if i go for 8TB and raidz1
Protected by smoothiebox Red,Green,
Purple,Orange Zones/VLAN`s
Powered by AMD A10-6700T


XigmaNAS Box-1 11.2.0.4 - Omnius (revision 6625)
Platform : x64-embedded on 2X Intel(R) Xeon(R) CPU E5-2620 v4 @ 2.10GHz
Motherboard: ASUS Z10PA-D8, 2xSocket-2011-3
SATA Controllers : 1X Avago Technologies (LSI) SAS2008 and 1x Avago Technologies (LSI) SAS2308
Pool 1 (Media-Pool) 8X4TB in raidz2
Pool 2 (Media-Pool-2) 4X2TB in raidz2 and 2X2TB in mirror mirror and 2X3TB in mirror
Pool 3 (Media-Pool-3) 2X2TB in mirror and 2X4TB in mirror and 2X1TB in mirror

User avatar
ChriZathens
Forum Moderator
Forum Moderator
Posts: 833
Joined: 23 Jun 2012 09:14
Location: Athens, Greece
Contact:
Status: Offline

Re: Which one of those?

#10

Post by ChriZathens » 13 Apr 2017 00:16

Looks like a nice board..
I would personally prefer something like the Supermicro x10drl-i, since it has integrated ikvm, but what i like about the Asus more is that it has 2x16 pcie slots.
And the Asus is probably cheaper...
My Nas
  1. Case: Fractal Design Define R2
  2. M/B: Supermicro x9scl-f
  3. CPU: Intel Celeron G1620
  4. RAM: 16GB DDR3 ECC (2 x Kingston KVR1333D3E9S/8G)
  5. PSU: Chieftec 850w 80+ modular
  6. Storage: 8x2TB HDDs in a RaidZ2 array ~ 10.1 TB usable disk space
  7. O/S: XigmaNAS 11.2.0.4.6625 -amd64 embedded
  8. Extra H/W: Dell Perc H310 SAS controller, crosflashed to LSI 9211-8i IT mode, 8GB Innodisk D150SV SATADOM for O/S

Backup Nas: HP N40L (4x1TB HP branded Seagate disks in RaidZ configuration - 8GB ECC RAM)

User avatar
lindsay
Forum Moderator
Forum Moderator
Posts: 307
Joined: 23 Jun 2012 09:59
Location: Steinkjer,Norway
Status: Offline

Re: Which one of those?

#11

Post by lindsay » 15 Apr 2017 15:56

I Wonder if Intel Xeon E5-2620 V4 is compatible With the mainboard?
It is Nice With HyperThread -Support on the CPU
Protected by smoothiebox Red,Green,
Purple,Orange Zones/VLAN`s
Powered by AMD A10-6700T


XigmaNAS Box-1 11.2.0.4 - Omnius (revision 6625)
Platform : x64-embedded on 2X Intel(R) Xeon(R) CPU E5-2620 v4 @ 2.10GHz
Motherboard: ASUS Z10PA-D8, 2xSocket-2011-3
SATA Controllers : 1X Avago Technologies (LSI) SAS2008 and 1x Avago Technologies (LSI) SAS2308
Pool 1 (Media-Pool) 8X4TB in raidz2
Pool 2 (Media-Pool-2) 4X2TB in raidz2 and 2X2TB in mirror mirror and 2X3TB in mirror
Pool 3 (Media-Pool-3) 2X2TB in mirror and 2X4TB in mirror and 2X1TB in mirror
